Page #150 background imageLoading...
Page #150 background image
LED Operator Display Minor Fault Name
oL3
Overtorque 1
Drive output current was greater than L6-02 for longer than the time set in L6-03.
Cause Possible Solutions
Minor Fault
Output
(H2-01 = 10)
Inappropriate parameter
settings.
Check parameters L6-02 and L6-03. YES
There is a fault on the machine
side (e.g., the machine is
locked up).
Check the status of the machine.
Remove the cause of the fault.
YES
LED Operator Display Minor Fault Name
ov
DC Bus Overvoltage
The DC bus voltage exceeded the trip point.
For 200 V class: approximately 410 V
For 400 V class: approximately 820 V (740 V when E1-01 < 400)
Cause Possible Solutions
Minor Fault
Output
(H2-01 = 10)
Surge voltage present in the
drive input power.
Install a DC reactor or an AC reactor.
Voltage
surge
can
result
from
a
thyristor
convertor and a phase
advancing capacitor operating on the same drive input power
system.
YES
The motor is short-
circuited.
Ground current has
over-charged the main
circuit capacitors via the
drive input power.
Check the motor power cable, relay terminals and motor
terminal box for short circuits.
Correct grounding shorts and turn the power back on.
YES
Noise interference causes the
drive to operate incorrectly.
Review possible solutions for handling noise interference.
Review section on handling noise interference and check
control circuit lines, main circuit lines and ground wiring.
If the magnetic contactor is identified as a source of noise,
install a surge protector to the MC coil.
YES
Set number of fault restarts (L5-01) to a value other than 0. YES
LED Operator Display Minor Fault Name
PASS MEMOBUS/Modbus Communication Test Mode Complete
Cause Possible Solutions
Minor Fault
Output
(H2-01 = 10)
MEMOBUS/Modbus test has
finished normally.
This verifies that the test was successful. No output
LED Operator Display Minor Fault Name
SE MEMOBUS/Modbus Communication Test Mode Error
5.5 Alarm Detection
150
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
