YASKAWA CIMR-JB Series User Manual

CIMR - J A 2 A
0001 B
A A
Drive
J1000
Series
No.
Enclosure Type
Design
Revision
Order
No.
Customized
Specifications
A Standard model
IP20/
Open-Chassis
B
No. Voltage Class
B
1-phase, 200-240 Vac
3-phase, 380-480 Vac
3-phase, 200-240 Vac
2
4
No.
Environmental
Specification <1>
A
M
N
S
Standard
Humidity- and
dust-resistant
Oil-resistant
Vibration-resistant
No.
Region
Code
A Japan
B China
C Europe
T Asia
U USA
Refer to the tables below.
<1> Drives with these specifications do not guarantee complete protection for the specified
environmental condition.
n
Single-Phase 200 V
Normal Duty Heavy Duty
No.
Max. Motor
Capacity kW
Rated Output
Current A
No.
Max. Motor
Capacity kW
Rated Output
Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0003 0.75 3.3 0003 0.4 3.0
0006 1.1 6.0 0006 0.75 5.0
0010 2.2 9.6 0010 1.5 8.0
1.2 Model Number and Nameplate Check
24
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual

YASKAWA CIMR-JB Series Specifications
