YASKAWA CIMR-JB Series User Manual

n
Three-Phase 200 V
Normal Duty Heavy Duty
No.
Max Motor
Capacity kW
Rated Output
Current A
No.
Max Motor
Capacity kW
Rated Output
Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0004 0.75 3.5 0004 0.4 3.0
0006 1.1 6.0 0006 0.75 5.0
0008 1.5 8.0 0008 1.1 6.9
0010 2.2 9.6 0010 1.5 8.0
0012 3.0 12.0 0012 2.2 11.0
0018 3.7 17.5 0018 3.0 14.0
0020 5.5 19.6 0020 3.7 17.5
n
Three-Phase 400 V
Normal Duty Heavy Duty
No.
Max. Motor
Capacity kW
Rated Output
Current A
No.
Max. Motor
Capacity kW
Rated Output
Current A
0001 0.4 1.2 0001 0.2 1.2
0002 0.75 2.1 0002 0.4 1.8
0004 1.5 4.1 0004 0.75 3.4
0005 2.2 5.4 0005 1.5 4.8
0007 3.0 6.9 0007 2.2 5.5
0009 3.7 8.8 0009 3.0 7.2
0011 5.5 11.1 0011 3.7 9.2
1.2 Model Number and Nameplate Check
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
25
1
Receiving
