Three-Phase 200 V / 400 V Class
B
C
D
E
D
F
A
G
J
I
H
L3
L2
L1
E
L1
PE
L3
L2
PE
A – Ground the cable shield
B – Enclosure panel
C – Metal plate
D – Grounding surface
(remove any paint or
sealant)
E
– Drive
F – Motor cable (braided
shield cable, max. 20 m)
G – Motor
H – Cable clamp
I – Wiring distance as short
as possible
J – EMC noise filter
Figure C.3 EMC Filter and Drive Installation for CE Compliance
(Three-Phase 200 V / 400 V Class)
C.2 European Standards
260
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
