YASKAWA CIMR-JB Series

Table C.8 Wire Gauge and Torque Specifications
Drive
Model
Terminal
For Japan and Asia
<1>
For United States
<2>
For Europe and China
<3>
Screw
Size
Tightening
Torque
N•m (lb.in.)
Recomm.
Gauge
mm
2
Wire Range
mm
2
Recomm.
Gauge
AWG,
kcmil
Wire Range
AWG, kcmil
Recomm.
Gauge
mm
2
Wire Range
mm
2
2A0001
2A0002
2A0004
2A0006
R/L1, S/L2,
T/L3
2 0.75 to 2 14 18 to 14 2.5 0.75 to 2.5
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2,
W/T3
2 0.75 to 2 14 18 to 14 2.5 0.75 to 2.5
⊖, ⊕1, ⊕2
2 0.75 to 2 – 18 to 14 – 0.75 to 2.5
B1, B2 2 0.75 to 2 – 18 to 14 – 0.75 to 2.5
2 0.75 to 2 14 18 to 14 2.5 0.75 to 2.5
2A0008
2A0010
R/L1, S/L2,
T/L3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
2 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
2 2 to 5.5 10 14 to 10 2.5 2.5 to 6
2A0012
R/L1, S/L2,
T/L3
2 2 to 5.5 12 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
2 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
2 2 to 5.5 10 14 to 10 2.5 2.5 to 6
2A0018
R/L1, S/L2,
T/L3
3.5 2 to 5.5 10 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
3.5 2 to 5.5 10 14 to 10 2.5 2.5 to 6
⊖, ⊕1, ⊕2
3.5 2 to 5.5 – 14 to 10 – 2.5 to 6
B1, B2 2 2 to 5.5 – 14 to 10 – 2.5 to 6
3.5 2 to 5.5 10 14 to 10 2.5 2.5 to 6
C.3 UL Standards
266
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
