Page #267 background image
Drive
Model
Terminal
For Japan and Asia
<1>
For United States
<2>
For Europe and China
<3>
Screw
Size
Tightening
Torque
N•m (lb.in.)
Recomm.
Gauge
mm
2
Wire Range
mm
2
Recomm.
Gauge
AWG,
kcmil
Wire Range
AWG, kcmil
Recomm.
Gauge
mm
2
Wire Range
mm
2
2A0020
R/L1, S/L2,
T/L3
5.5 2 to 5.5 10 14 to 10 4 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
3.5 2 to 5.5 10 14 to 10 2.5 2.5 to 6
, 1, 2
5.5 2 to 5.5 14 to 10 2.5 to 6
B1, B2 2 2 to 5.5 14 to 10 2.5 to 6
3.5 2 to 5.5 10 14 to 10 4 2.5 to 6
<1> Gauges listed here are for use in Japan and Asia.
<2> Gauges listed here are for use in the United States.
<3> Gauges listed here are for use in Europe and China.
Table C.9 Wire Gauge and Torque Specifications
Drive
Model
Terminal
For Japan and Asia
<1>
For United States
<2>
For Europe and China
<3>
Screw
Size
Tightenin
g
Torque
N•m
(lb.in.)
Recomm.
Gauge
mm
2
Wire Range
mm
2
Recomm.
Gauge
AWG,
kcmil
Wire Range
AWG, kcmil
Recomm.
Gauge
mm
2
Wire Range
mm
2
4A0001
4A0002
4A0004
R/L1, S/L2,
T/L3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
, 1, 2
2 2 to 5.5 14 to 10 2.5 to 6
B1, B2 2 2 to 5.5 14 to 10 2.5 to 6
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
4A0005
4A0007
4A0009
R/L1, S/L2,
T/L3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
M4
1.2 to 1.5
(10.6 to
13.3)
U/T1, V/T2,
W/T3
2 2 to 5.5 14 14 to 10 2.5 2.5 to 6
, 1, 2
2 2 to 5.5 14 to 10 2.5 to 6
B1, B2 2 2 to 5.5 14 to 10 2.5 to 6
2 2 to 5.5 10 14 to 10 2.5 2.5 to 6
C.3 UL Standards
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
