<2> All codes in the far right column of the table above refer to a set including three crimp terminals and three
insulation
caps.
Input
and
output
wiring
must
be prepared by the user. Two sets should be used for each terminal
connection.
Example: Drive model BA0001 with 14 AWG for both input and output should use one set for input and one
set for output. The user should therefore order a total of two sets of [100-066-218].
Note: Consider the amount of voltage drop when selecting wire gauges. Increase the wire gauge when the
voltage drop is greater than 2% of motor rated voltage. Ensure the wire gauge is suitable for the terminal
block. Use the following formula to calculate the amount of voltage drop:
Line drop voltage (V) =
3 × wire resistance (Ω/km) × wire length (m) × current (A) × 10
-3
n
Factory Recommended Branch Circuit Protection
Yaskawa recommends installing one of the following types of branch circuit protection to
maintain compliance with UL508C. Semiconductor protective type fuses are preferred.
Alternate branch circuit protection devices are also listed in Table C.11.
Branch circuit protection shall be provided by any of the following:
• Non-time delay Class J, T, or CC fuses sized at 300% of the drive input rating
Note: The following model/fuse combinations
are excluded from the preceding statement:
2A0002/A6T6, 2A0004/A6T15, 4A0004/A6T15, 4A0005/A6T20, and 4A0007/A6T25.
• Time delay Class J, T, or CC fuses sized at 175% of the drive input rating
• Time-delay Class RK5 fuses sized at 225% of the drive input rating
Table C.11 Factory Recommended Drive Branch Circuit Protection
Drive Model
Non-Time Delay
Class T Fuse Type
(Manufacturer: Ferraz)
Rated Voltage:
600 Vac, 200 kAIR
Fuse Ampere
Rating (A)
Fuse Type
(Manufacturer:
Bussmann)
Rated Voltage:
500 Vac, 200 kAIR
Fuse Ampere
Rating (A)
200 V Class Single-Phase Drives
BA0001 A6T6 6 FWH-25A14F 25
BA0002 A6T10 10 FWH-25A14F 25
BA0003 A6T20 20 FWH-60B 60
BA0006 A6T40 40 FWH-80B 80
BA0010 A6T40 40 FWH-100B 100
200 V Class Three-Phase Drives
2A0001 A6T3 3 FWH-25A14F 25
2A0002 A6T6 6 FWH-25A14F 25
2A0004 A6T15 15 FWH-25A14F 25
2A0006 A6T20 20 FWH-25A14F 25
2A0008 A6T25 25 FWH-70B 70
2A0010 A6T25 25 FWH-70B 70
2A0012 A6T25 25 FWH-70B 70
C.3 UL Standards
270
YASKAWA ELECTRIC TOEP C710606 25D YASKAWA AC Drive J1000 Installation & Start-Up Manual
