YASKAWA MOTOMAN-MPX2600 User Manual

5-5
180788-1CD
HW1484370
5 Basic Specifications
5.5 Appearance and Dimensions of the Pressure Switch Unit
MPX2600
5.5 Appearance and Dimensions of the Pressure Switch Unit
Fig. 5-4: Outline View of the Pressure Switch Unit
Purging pressure:
0.18 to 0.20 [MPa]
Operating pressure:
0.01 to 0.02 [MPa]
Air inlet
0.35 to 0.65 [MPa]
(tube: 16 dia.)
Air inlet
From the manipulator
(tube: 16 dia.)
To the manipulator
(tube: 16 dia.)
Exhaust port
210.8
5
407.5
398.9
200.8
207.9
256.6
ユニファイ並目
六角ボルト5/16-18X1
ユニファイ並目
六角ナット5/16-18
KQ2L16-02S
M5X8
M4
M5M5
M5X8M5X8M5X8M5X8
M3X6M3X6
ユニファイ並目
六角ボルト5/16-18X1
M4
KQ2L16-02S
KQ2L16-02S
M4
M5
M5
M5
M5
61 of 116
