2.5 Communications with a Touch Panel
Using Automatic Reception with the MP3000 as a Slave
2-97
Ethernet Communications
 Screen Creation Example
1.
Create a base screen.
2. From the tool bar, select Data Display and place the object on the screen.
3. Double-click the Data Display placed on the screen.
4. Enter the following settings in the Data Display Dialog Box and click the OK Button.
• The following table shows the relationship between the address display in GP-Pro EX and registers in the
MP3000.
 Starting Communications
1. Turn ON the power to the MP3000 to start receiving messages.
The system will automatically start the message reception operation. No further operation is required.
2. Start the GP3000-series Touch Panel to display the main screen.
Communications with the MP3000 will start after the touch panel operating system starts.
Note: Contact Digital Electronics Corporation for further information.
Display Data Numeric Display
Monitor Word Address GMW00100
Device
Address Display in
GP-Pro EX
Registers in MP3000
Coils as bits GMB MB
Coils as words GMW MW
Input relays as bits GIB IB
Input relays as words GIW IW
12345
GP-Pro EX Screen
Place here
12345
GP-Pro EX Screen
Double-click
