2.8 Communications with an OMRON PLC (FINS Communications Service)
Message Functions
2-233
Ethernet Communications
Note: W: Word (channel) data
 Reserved for System (PARAM13)
This parameter is used by the system.
 Remote Station Data Address (PARAM14 and PARAM15)
Set the first address for data in the remote station.
Enter the first address as a decimal or hexadecimal number.
The applicable function codes and valid range of data addresses depend on the I/O memory type and the
range of the OMRON PLC.
Note: 1. Even if addresses are within the given address range, they may exceed the range of the I/O memory area depend-
ing on the model of the OMRON PLC.
Refer to the following manual for details.
OMRON PLC manuals
2. The corresponding register address in the MP3000 can be adjusted by using the offset setting of the MSG-SNDE
function.
0F hex 01 hex 02 hex
B0 hex W Writes to CIO Area words.
B1 hex W Writes to Work Area words.
B2 hex W Writes to Holding Area words.
B3 hex W Writes to Auxiliary Area words.
0B or 10 hex 01 hex 02 hex 82 hex W Writes to DM Area words.
0D hex 01 hex 04 hex 82 hex W
Reads non-consecutive words from the DM
Area.
Do not change the value of PARAM13 from a user program or by any other means.
If the first address is MW01000, enter “1000” (decimal) or “3E8” (hexadecimal).
Bit Conversion Table
Data Area Address Range Notation Function Code
Data Address
Setting Range
Corresponding
Register
Addresses
CIO Area 0000 to 2047 Decimal 01 and 0F hex: Coils 0 to 32767
MB000000 to
MB02047F
Work Area W000 to W511 Decimal 01 and 0F hex: Coils 32768 to 40959
MB020480 to
MB02559F
Holding Bits H00000 to H51115 Decimal 01 and 0F hex: Coils 40960 to 49151
MB025600 to
MB03071F
Auxiliary Bits
A000 to A447
(read only)
A448 to A959
(read/write)
Decimal 01 and 0F hex: Coils
49152 to 56319
56320 to 64511
MB030720 to
MB03519F
MB035200 to
MB04031F
DM Area Conversion Table
Data Area Address Range Notation Function Code
Data Address
Setting Range
Corresponding
Register
Addresses
DM Area D00000 to D32767 Decimal
03, 09, 0B, 0D, and 10
hex: Hold registers
0 to 32767
MW00000 to
MW32767
Continued from previous page.
MEMOBUS
Function Code
FINS Command Code
Target
Data
Type
Function
MR SR
I/O Memory
Type
Note
Example
