2.2 Detail Definition Setting Procedures
218IFD Detail Definition Dialog Box Details
2-8
 Display Items
The following table lists the items that are displayed on the Transmission Parameters Tab Page.
For the valid setting ranges and setting precautions, refer to the descriptions of the items on the following
pages.
 Display Item Details
This section provides details on the items that are displayed on the Transmission Parameters Tab Page.
 IP Address
Enter the IP address of the local station.
There are four 8-bit fields delimited by periods. Input a decimal number in each field.
Note: 1. Enter an IP address that is not in use by another node on the Ethernet.
2. IP addresses 192.168.1.1 to 192.168.1.254 are recommended as private addresses. Check with your net-
work administrator for unused IP addresses.
 Subnet Mask
Enter the subnet mask for the IP address of the local station.
Fields 1 to 3 can be set to 0 to 255. Field 4 can be set to 1 to 254. When a subnet mask is not being used, enter
0 in fields 1 to 4.
Number Item Description

IP Address Sets the IP address of the local station.

Subnet Mask Sets the subnet mask for the IP address of the local station.

Gateway IP Address Sets the IP address of the gateway.

Module Name Definition Sets the name for the 218IFD.

Detail Definition Button Click to set details for the local station.

Connection Number (CNO) Displays the connection number.

Local Port Sets the local port number.

Node IP Address Sets the remote IP address.

Node Port Sets the port number for the remote station.

Connect Type Sets the transport layer protocol.
Protocol Type Sets the application layer protocol.
Code Sets the code type.
Detail
Used to set automatic reception and the local station for the
FINS protocol.
Node Name
(Remote Station Name)
Used to enter a comment for the connection.
Always save all settings to the flash memory after changing them.
11
12
13
14
Note
11000000 10101000 00000001 00000001
Field 1: 0 to 255 excluding 127
Field 2: 0 to 255
Field 3: 0 to 255
Field 4: 1 to 254
Least significant bitMost significant bit
