2.9 Communications with a KOYO PLC (MODBUS/TCP Protocol)
Using Automatic Reception with the MP3000 as a Slave
2-255
Ethernet Communications
 Setting the Remote Device (KOYO PLC)
Use the following procedure to set the KOYO DL-series PLC.
1. Start DirectSoft32.
2. Create a project.
3. Start NetEdit3.
4. Click the ECOM Settings Tab followed by the General Button in the Configuration Area to set
the network parameters.
5. Click the ECOM Settings Tab followed by the Peer to Peer Config Button in the Configuration
Area to set the MODBUS/TCP parameters.
Note: Specify an IP address that is not in use by any other device on the same network.
Check with your network administrator for unused IP addresses.
The DL-series PLCs are manufactured by KOYO Electronics Industries.
Contact KOYO Electronics Industries for further information.
Parameter Description
Select the Use the following IP settings Option before setting the following items.
IP Address 192.168.1.2
Subnet mask 255.255.255.0
Others As required.
Parameter Description
RX/WX Device Number 1
Select the
Modbus-TCP Option before setting the following items.
IP Address 192.168.1.1
Port 10001
Unit ID 0
Note
