2.13 Communications with a Windows PC (Visual C++ Application)
Using Automatic Reception with the MP3000 as a Slave
2-341
Setting Example
The following figure illustrates how the contents of the MW00000 to MW00009 hold registers in the
MP3000 slave are displayed on a form created in Microsoft Visual C++.
TCP
Binary
Ethernet
Ethernet
MW00000
MW00001
MW00009
MW00008
MP3000
(local station)
IP address: 192.168.001.001
PC (Visual C++)
(remote station)
IP address: 192.168.001.002
Slave
Communications Protocol
Extended MEMOBUS
Connection Type
Data Code
Master
Port number: 10001
Port number: 10001
Local Station
Hold registers (M registers)
Read.
Data size:
10 words
Remote Station
VC++ application
To Next Page
