2.13 Communications with a Windows PC (Visual C++ Application)
Using Automatic Reception with the MP3000 as a Slave
2-342
MP3000 Setup
Use the following procedure to set up the MP3000.
1.
Double-click the cell for 218IFD in the Module Configuration Definition Tab Page.
The 218IFD Detail Definition Dialog Box will be displayed.
2.
Set the communications parameters.
In the
IP Address
Boxes, enter the following address: 192.168.001.001.
In the
Subnet Mask
Boxes, enter the following mask: 255.255.255.000.
In the
Gateway IP Address
Boxes, enter the following address: 000.000.000.000.
3.
Click the
Easy Setting
Button in the
Message Communication
Area in the
Connection Parame-
ter
Area.
The Message Communications Easy Setting Dialog Box will be displayed.
If the communications parameters (IP address and subnet mask) have already been set, skip to step 3.
To Next Page
