3.2 Function Modules
3.2.5 Data Logging
3-79
3
CPU Module Functionality
The following example shows how the register data is given for the settings and con-
ditions listed below.
File Details to Output
• Data No. and DATE/TIME are selected
Targ e t Regi s t er to L o g
• MW00000
Status
• Data No.: 000001
• DATE/TIME: 2011/06/23 18:02:19
• Value of MW00000 register: 100
Actual Data
The data is stored in little endian as shown below.
01 00 00 00 00 00 00 00 11 00 23 06 02 18 19 00 64 00
MW00000 = 100
DATE/TIME =
2011/06/23 18:02:19
Data No. = 1
To Next Page
