4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-23
System I/O Error Status
The data in these registers give the I/O errors in the system for Rack 1.
The details of the error status depend on the Modules that are mounted and the error code.
Refer to the following manual for details.
MP3000 Series MP3200/MP3300 Troubleshooting Manual (Manual No.: SIEP C880725 01)
Security Status
The data in these registers give the status of CPU Module security.
Name Register Address Remarks
I/O Error Count SW00200 Number of I/O error occurrences
Input Error Count SW00201 Number of input error occurrences
Input Error Address SW00202 Latest input error address (register address in IW)
Output Error Count SW00203 Number of output error occurrences
Output Error Address SW00204
Latest output error address (register address in
OW)
Reserved for system.
SW00205 to
SW00207
−
I/O Error Status
SW00208 to
SW00215
Error status of Rack 1, Slot 0
SW00216 to
SW00223
Reserved for system.
SW00224 to
SW00231
Error status of Rack 1, Slot 1 (Depends on the Module
that is mounted and the error code.)
SW00232 to
SW00239
Error status of Rack 1, Slot 2 (Depends on the Modules
that are mounted and the error code.)
SW00240 to
SW00247
Error status of Rack 1, Slot 3 (Depends on the Modules
that are mounted and the error code.)
SW00248 to
SW00255
Error status of Rack 1, Slot 4 (Depends on the Modules
that are mounted and the error code.)
SW00496 to
SW00503
Error status of Rack 4, Slot 9 (Depends on the Modules
that are mounted and the error code.)
Name Register Address Contents
Security
Status
SW00506
0: Security disabled,
1: Security enabled
Security Read
Protection
Information
SW00507
SB005070 to
SB005073
Restriction rights for file
reading
SB005074 to
SB005076
Reserved for system.
SB005077 File reading restriction
SB005078 to
SB00507F
Reserved for system.
hex
Restriction rights level (0
to 7)
Reserved for system.
File reading restriction
0: Not restricted
1: Restricted
Reserved for system.
