4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-24
 USB-related System Status
The data in these registers give information on the USB memory and give the error status.
 Message Relaying Status
The data in these registers give the message relaying status in the CPU Module.
Name Register Address Remarks
Available USB Memory SL00650
Unit: Kilobytes
Total USB Memory SL00652
USB Status SW00654
SB006540
0: No USB memory device
1: USB memory device inserted
SB006541
0: Not supplying power
1: Supplying power
SB006542
0: Cannot recognize USB memory device
1: Recognized USB memory device
SB006543
0: Not accessing USB memory device
1: Accessing USB memory device
SB006544
0: −
1: Checking FAT file system
SB006545 to
SB00654F
Reserved for system.
FAT Type SW00655
0002 hex FAT16
0003 hex FAT32
Reserved for system. SW00656 and SW00657 −
Batch Load and Batch
Save
SW00658
SB006580 1: Batch load in progress
SB006581 1: USB memory read error
SB006582 1: Load file model mismatch error
SB006583 1: Load file write error
SB006584 1: Save to flash memory error
SB006585 1: Folder for batch loading does not exist
SB006586
1: Loading error due to program write protec-
tion
SB006587 Reserved for system.
SB006588 1: Batch save in progress
SB006589 1: USB memory write error
SB00658A 1: Save file read error
SB00658B 1: Security error
SB00658C to
SB00658F
Reserved for system.
Reserved for system. SW00659 to SW00667 −
Name Register Address Contents
Message Relaying Information
SW00694 Normally processed command message counter
SW00695 Command message error counter
SW00696 Normally processed response message counter
SW00697 Response message error counter
