YASKAWA MP3300 series User Manual

4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-26
 Module Information
The data in these registers give hardware information about the CPU Module and Optional
Modules on Rack 1.
Name Register Address Remarks
CPU Module
Information
SW00800 CPU Module ID
SW00801 Hardware version (BCD)
SW00802 Software version (BCD)
SW00803 Number of sub-slots (hex)
SW00804 Function Module 1 ID (hex)
SW00805 Function Module 1 Status
SW00806 Function Module 2 ID (hex)
SW00807 Function Module 2 Status
SW00808 Function Module 3 ID (hex)
SW00809 Function Module 3 Status
SW00810 Function Module 4 ID (hex)
SW00811 Function Module 4 Status
SW00812 Function Module 5 ID (hex)
SW00813 Function Module 5 Status
SW00814 Function Module 6 ID (hex)
SW00815 Function Module 6 Status
Optional Module
Information
SW00816
Rack 1 Unit 1
Slot 1
Module ID
SW00817 Hardware version (BCD)
SW00818 Software version (BCD)
SW00819 Number of sub-slots
SW00820 ID of Function Module 1
SW00821
Status of Function Module
1
SW00822 ID of Function Module 2
SW00823
Status of Function Module
2
SW00824 to SW00831 Slot 2 Same as above.
SW00832 to SW00839 Reserved for system.
SW00840 to SW00879 Slot 4 Same as above.
Continued on next page.
