4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-28
MPU-01 Module Status
The data in these registers give the status of the MPU-01 Multi-CPU Module.
Name
Register
Address
Contents
MPU-01 Module
Status
SW01411 Status of MPU-01 Module circuit number 1
SW01412 Error status of MPU-01 Module circuit number 1
SW01413 Status of MPU-01 Module circuit number 2
SW01414 Error status of MPU-01 Module circuit number 2
SW01415 Status of MPU-01 Module circuit number 3
SW01416 Error status of MPU-01 Module circuit number 3
SW01417 Status of MPU-01 Module circuit number 4
SW01418 Error status of MPU-01 Module circuit number 4
SW01419 Status of MPU-01 Module circuit number 5
SW01420 Error status of MPU-01 Module circuit number 5
SW01421 Status of MPU-01 Module circuit number 6
SW01422 Error status of MPU-01 Module circuit number 6
SW01423 Status of MPU-01 Module circuit number 7
SW01424 Error status of MPU-01 Module circuit number 7
SW01425 Status of MPU-01 Module circuit number 8
SW01426 Error status of MPU-01 Module circuit number 8
SW01427 Status of MPU-01 Module circuit number 9
SW01428 Error status of MPU-01 Module circuit number 9
SW01429 Status of MPU-01 Module circuit number 10
SW01430 Error status of MPU-01 Module circuit number 10
SW01431 Status of MPU-01 Module circuit number 11
SW01432 Error status of MPU-01 Module circuit number 11
SW01433 Status of MPU-01 Module circuit number 12
SW01434 Error status of MPU-01 Module circuit number 12
SW01435 Status of MPU-01 Module circuit number 13
SW01436 Error status of MPU-01 Module circuit number 13
SW01437 Status of MPU-01 Module circuit number 14
SW01438 Error status of MPU-01 Module circuit number 14
SW01439 Status of MPU-01 Module circuit number 15
SW01440 Error status of MPU-01 Module circuit number 15
SW01441 Status of MPU-01 Module circuit number 16
SW01442 Error status of MPU-01 Module circuit number 16
