4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-29
4
Specications
 PROFINET Controller (266IF-01) IOPS Status Information
The data in these registers give the IOPS status information for the PROFINET Controller
(266IF-01).

Register Configuration
Register Address Remarks
SW02688 to SW02695
Circuit 1
IOPS Output –
SW02696 to SW02749 IOPS Status
The input IOPS status from the slaves
(54 words)
SW02750 to SW02751 Reserved for system. –
SW02752 to SW02815 Circuit 2 Same as above.
SW02816 to SW02879 Circuit 3 Same as above.
SW02880 to SW02943 Circuit 4 Same as above.
SW02944 to SW03007 Circuit 5 Same as above.
SW03008 to SW03071 Circuit 6 Same as above.
SW03072 to SW03135 Circuit 7 Same as above.
SW03136 to SW03199 Circuit 8 Same as above.
