YASKAWA MP3300 series User Manual

4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-53
4
Specications
 Expanded Unit and Module Information
The data in these registers give hardware information about the CPU Module and Optional
Modules on Rack 1.
Name Register Addresses Remarks
CPU Module
Information
SW13700 CPU Module ID (Low)
SW13701 CPU Module ID (High)
SW13702 Hardware version (BCD)
SW13703 Software version (BCD)
SW13704 Number of sub-slots (hex)
SW13705 to SW13707 Reserved for system.
SW13708 Function Module 1 ID (Low)
SW13709 Function Module 1 ID (High)
SW13710 Function Module 1 Status
SW13711 Reserved for system.
SW13712 Function Module 2 ID (Low)
SW13713 Function Module 2 ID (High)
SW13714 Function Module 2 Status
SW13715 Reserved for system.
SW13716 Function Module 3 ID (Low)
SW13717 Function Module 3 ID (High)
SW13718 Function Module 3 Status
SW13719 Reserved for system.
SW13720 Function Module 4 ID (Low)
SW13721 Function Module 4 ID (High)
SW13722 Function Module 4 Status
SW13723 Reserved for system.
SW13724 Function Module 5 ID (Low)
SW13725 Function Module 5 ID (High)
SW13726 Function Module 5 Status
SW13727 Reserved for system.
SW13728 Function Module 6 ID (Low)
SW13729 Function Module 6 ID (High)
SW13730 Function Module 6 Status
SW13731 Reserved for system.
SW13732 Function Module 7 ID (Low)
SW13733 Function Module 7 ID (High)
SW13734 Function Module 7 Status
SW13735 Reserved for system.
SW13736 Function Module 8 ID (Low)
SW13737 Function Module 8 ID (High)
SW13738 Function Module 8 Status
SW13739 Reserved for system.
SW13740 Function Module 9 ID (Low)
SW13741 Function Module 9 ID (High)
SW13742 Function Module 9 Status
SW13743 Reserved for system.
SW13744 Function Module 10 ID (Low)
SW13745 Function Module 10 ID (High)
SW13746 Function Module 10 Status
SW13747 Reserved for system.
Continued on next page.
