4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-54
 Expansion System Service Execution Status
The data in these registers give the execution status of the system when the Units are
expanded.
Unit and Optional
Module
Information
SW13748
Rack 1 Unit 1
Slot 1
Optional Unit and Module
ID (Low)
SW13749
Optional Unit and Module
ID (High)
SW13750 Hardware version (BCD)
SW13751 Software version (BCD)
SW13752 Number of sub-slots (hex)
SW13753 to SW13755 Reserved for system.
SW13756
Function Module 1 ID
(Low)
SW13757
Function Module 1 ID
(High)
SW13758 Function Module 1 Status
SW13759 Reserved for system.
SW13760
Function Module 2 ID
(Low)
SW13761
Function Module 2 ID
(High)
SW13762 Function Module 2 Status
SW13763 Reserved for system.
SW13764 to SW13779 Slot 2
Same as above.
SW13780 to SW13795 Slot 3
SW13796 to SW14259 Reserved for system.
The Optional Module information data for Racks 2 to 4 is stored in SW00880 to SW01095.
Refer to the following sections for details.
 Module Information on page 4-26
Name Register Addresses Remarks
Data Trace Definition
Existence
SW15998
SB159980 Group 1
0: Definition does not
exist,
1: Definition exists
SB159981 Group 2
SB159982 Group 3
SB159983 Group 4
SB159984 to SB15998F Reserved for system.
Data Trace Execution
Status
SW15999
SB159990 Group 1
0: Tracing in prog-
ress, 1: Tracing
stopped
SB159991 Group 2
SB159992 Group 3
SB159993 Group 4
SB159994 to SB15999F Reserved for system.
Group 1 Record No. SL16000 Latest record number in group 1.
Group 2 Record No. SL16002 Latest record number in group 2.
Group 3 Record No. SL16004 Latest record number in group 3.
Group 4 Record No. SL16006 Latest record number in group 4.
Reserved for system. SL16008 Reserved for system.
Reserved for system. SL16010 Reserved for system.
Continued from previous page.
Name Register Addresses Remarks
Information
