4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-66
Circuit
Number 7
Common
Status
SW25504 Rack No.
SW25505 Unit No.
SW25506 Slot No.
SW25507 Sub-slot No.
CH1 Status
SW25508
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25509
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25510 Transmission pass counter
SW25511 Reception pass counter
SW25512 Error counter
SW25513 to
SW25515
Reserved for system.
CH2 Status
SW25516 to
SW25523
Same as CH1 status.
CH3 Status
SW25524 to
SW25531
Same as CH1 status.
CH4 Status
SW25532 to
SW25539
Same as CH1 status.
CH5 Status
SW25540 to
SW25547
Same as CH1 status.
CH6 Status
SW25548 to
SW25555
Same as CH1 status.
CH7 Status
SW25556 to
SW25563
Same as CH1 status.
CH8 Status
SW25564 to
SW25571
Same as CH1 status.
CH9 Status
SW25572 to
SW25579
Same as CH1 status.
CH10 Status
SW25580 to
SW25587
Same as CH1 status.
