4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-67
Transmission Status
Circuit
Number 8
Common
Status
SW25588 Rack No.
SW25589 Unit No.
SW25590 Slot No.
SW25591 Sub-slot No.
CH1 Status
SW25592
Transmission status
Refer to the following section for details.
Transmission Status on page 4-67
SW25593
Latest error status
Refer to the following section for details.
Error Status on page 4-68
SW25594 Transmission pass counter
SW25595 Reception pass counter
SW25596 Error counter
SW25597 to
SW25599
Reserved for system.
CH2 Status
SW25600 to
SW25607
Same as CH1 status.
CH3 Status
SW25608 to
SW25615
Same as CH1 status.
CH4 Status
SW25616 to
SW25623
Same as CH1 status.
CH5 Status
SW25624 to
SW25631
Same as CH1 status.
CH6 Status
SW25632 to
SW25639
Same as CH1 status.
CH7 Status
SW25640 to
SW25647
Same as CH1 status.
CH8 Status
SW25648 to
SW25655
Same as CH1 status.
CH9 Status
SW25656 to
SW25663
Same as CH1 status.
CH10 Status
SW25664 to
SW25671
Same as CH1 status.
Register Value Status Contents
0 − Unused connection.
1 IDLE Standby mode for executing message functions.
2 WAIT Waiting to establish a connection.
3 CONNECT Ready to send and receive data.
Continued from previous page.
Name Register Address Contents
To Next Page
