SVCMD_IO (I/O signal monitor) Bit Position Allocation
Allocation of bit position for monitoring the CN1-29, 30 output signal.
Same settings for the CN1-1, 2 output signal
Enables or disables the allocated bit position for monitoring the CN1-29, 30
output signal.
■Monitor Information
Monitors the CN1 output signal
OFF (Output transistor is open.)
ON (Output transistor is closed.)
Indicates the status of the CN1 output signal.
Use any of the Pn868, Pn869 and Pn86A to allocate bit positions for monitoring
the CN1 output signal.
When using these parameters, if the same bit position is allocated to more than
two signals, the logical OR operator is used to send a signal.
