2.4 Selecting Cables
2-7
2
2.4 Selecting Cables
2.4.1 Cables for SGMAS and SGMPS Servomotor
• Cable Connection for Standard Wiring Distance
Encoder cable


Servomotor main
circuit cable


SGMPS-08, 15 Servomotor
for 750 W, 1.5 kW
Servomotor
main circuit
cable (for relay)
Encoder cable
(for relay)
Battery case
(when an absolute
encoder is used.)
SGMAS and
SGMPS-01 to 04
Servomotor
for 100 to 400 W
SGMAS/SGMPS
SERVOPACK
