3.6 Dimensional Drawings of SERVOPACK Model SGDS-72
3-17
3
3.6 Dimensional Drawings of SERVOPACK Model SGDS-72
3.6.1 Classification table
SERVOPACK dimensional drawings are grouped according to the mounting method and capacity.
• Base-mounted type
3.6.2 Single-phase 100 V/200 V, 50 W/100 W/200 W
Power Supply
Voltage
Capacity Width
[mm]
Height
[mm]
Depth
[mm]
Volume
[mm
3
]
Reference
Section
Single-phase
100 V
50 W 55 150 130 1073 3.6.2
100 W
200 W
400 W 70 1463 3.6.3
Single-phase
200 V
50 W 55 1073 3.6.2
100 W
200 W
400 W 75 1463 3.6.3
750 W 70 180 1890 3.6.4
Three-phase
200 V
1.0 kW
Units: mm (in)
Approx. mass: 1.0 kg (2.20 lb)
CN5
CN6A
CN6B
CN3
CN1
CN2
18
(0.71)
Nameplate
2 × M4 screws
Outline
Terminals
130 (5.12)
100 (3.94)
55 (2.17)
150 (5.91)
(4.5) (1.78)
Mounting Hole Diagram
32±0.5
(1.26±0.02)
5
(0.20)
55 (2.17)
(18) (0.71)
139.5±0.5 (5.49±0.02)
150 (5.91)
5.5 (0.22)
(5) (0.20)
(Mounting pitch)
(Mounting pitch)
C
N
2
C
N
1
C
V
L
N
K
L
N
K
P
T
R
C
N
5
C
N
3
OUT
CN6A
POWER
IN
CN6B
ALM
SGDS-
SW1
SW
YASKAWA ELECTRIC
MADE IN JAPAN
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
Ground terminal
2
× M4 screws
