2.4 Selecting Cables
2-21
2
• Encoder Cable Extension from 20m (65.5 ft) up to 50m (164 ft)


A
View A
SGDS SERVOPACK
Servomotor
main circuit
cable
Encoder
cable
Servomotor
SGMCS
To be assembled by the customer.
Relay encoder cable extension
(Encoder end)
