3.1 SERVOPACK Ratings and Specifications
3-3
3
* Speed regulation is defined as follows:
The motor speed may change due to voltage variations or amplifier drift and changes in processing
resistance due to temperature variation. The ratio of speed changes to the rated speed represent speed
regulation due to voltage and temperature variations.
Speed regulation
No-load motor speed − Total load motor speed
Rated motor speed
×
100%
Applicable SERVOPACK Model SGDS-A572A to -3072A: For All Capacities
SynqNet
Communications
Baud Rate 100 Mbps
Transmission Cycle Multiple of 62.5 µs (set by the host controller)
Address Setting Select the address of 0 to 255 with using the rotary switch.
Reference
Method
Operating Specifications Torque control with using SynqNet communication
Reference Input SynqNet communication
Command: Torque reference
Fully-closed Control Fully-closed input (controlled by the host controller)
Built-in
Functions
Analog Monitor (CN5) Analog monitor connector built in for monitoring speed, torque.
Speed: 1 V/1000 min
-1
Torque: 1 V/rated torque
Communications Interface Digital operator (hand held type) via RS422A port or personal computer
via RS232C port
Axis Address
Setting
Parameter
Functions Status display, user constant setting, monitor display, alarm display, JOG
driving, speed and torque instruction signals, etc.
