YASKAWA V1000

7 Transfer of Parameter Settings
34 YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide
0x01CC B8-01
Energy Saving
Control Selection
Energy Savings function enable/disable
selection.
0: Disabled
1: Enabled (set b8-04)
2: PM Energy-saving control
0~2 0~1
A1-02
Depend
(all 0)
0
DEC
0x020A C1-11
Accel/Decel Switch
Frequency
Sets the frequency at which acceleration and
deceleration times are automatically changed.
0.0~590.0 0.0~400.0
A1-02
Depend
(all 0)
0.0
DEC Hz
0x0264 C1-14
Picking up speed and
slowing down rate
setting standard
frequency
Sets the base frequency used to calculate
acceleration and deceleration rates.
0.0~590.0 0.0~400.0 0.0 0.0
DEC Hz
0x0212 C3-04
Slip Compensation
Selection during
Regeneration
Enables or disables slip compensation during
regenerative operation.
0: Disabled
1: Enabled (6 Hz and above)
2: Enabled (compensation provided wherever
possible)
0~2 0~1 0 0
DEC
0x021C C5-02 ASR Integral Time 1
Sets the integral time of the speed control loop.
(ASR)
0.000~
60.000
0.000~
10.000
A1-02
Depend
A1-02
Depend
DEC sec
0x021E C5-04 ASR Integral Time 2
Sets the speed control gain 2 and integral time 2
of the speed control loop (ASR).
Note: Adjustment is not normally required.
0.000~
60.000
0.000~
10.000
A1-02
Depend
A1-02
Depend
DEC sec
0x0221 C5-07
ASR Gain Switching
Frequency
Sets the frequency for switching between
Proportional Gain 1, 2 and Integral Time 1, 2.
When ASR switch is set to one of the multi-
function input terminals, that switching value
take priority.
0.0~400.0 0.0~400.0
A1-02
Depend (all
0)
0.0
DEC Hz
0x0280
D1-
01~17
Frequency Reference
1~17
Setting units are determined by o1-03.
0.00~
590.00
0.00~
400.00
0.00 0.00
DEC
O1-
03
0x0294
D3-
01~3
Jump Frequency 1~3
Sets the median value of the specific frequency
band that needs to be jumped.
0.0~590.0 0.0~400.0
A1-02
Depend (all
0)
0.0
DEC Hz
0x0297 D3-04
Jump Frequency
Width
This parameter determines the width of the
deadband around each selected prohibited
frequency reference point. A setting of "1.0" will
result in a deadband of +/- 1.0 Hz.
0.0~20.0 0.0~20.0
A1-02
Depend (all
1.0)
1.0
DEC Hz
0x0303 E1-04
Max Output
Frequency (FMAX)
Sets the maximum output frequency for the V/f
pattern.
40.0~590.0 40.0~400.0
A1-02,E1-
03,O2-
09,E5-01
Depend
A1-02,E1-
03,O2-
09,E5-01
Depend
DEC
O1-
04
0x0305 E1-06 Bass Frequency (FA) Sets the base frequency for the V/f pattern.
0.0~590.0 0.0~400.0
A1-02,E1-
03,O2-
09,E5-01
Depend
A1-02,E1-
03,O2-
09,E5-01
Depend
DEC
O1-
04
0x0306 E1-07
Mid Output
Frequency (FB)
Sets the middle output frequency.
0.0~590.0 0.0~400.0
A1-02,E1-
03,O2-09
Depend
A1-02,E1-
03,O2-09
Depend
DEC
O1-
04
0x0308 E1-09
Minimum Output
Frequency (FMIN)
Sets the minimum output frequency for the V/f
pattern.
0.0~590.0 0.0~400.0
A1-02,E1-
03,O2-
09,E5-01
Depend
A1-02,E1-
03,O2-
09,E5-01
Depend
DEC
O1-
04
0x030A E1-11
Mid Output
Frequency 2
Set only when fine tuning the V/f pattern within
the constant power (HP) range above base speed.
This value seldom needs to be changed.
0.0~590.0 0.0~400.0
A1-02,E1-
03,O2-09
Depend
A1-02,E1-
03,O2-09
Depend
DEC
O1-
04
0x0311 E2-04
Number of Motor
Poles
Sets the number of motor poles. This value is
automatically set during Auto-Tuning.
2~120 2~48 4 4
DEC
Reg.
No.
Param.
No.
Name Description
Setting Range Initial Setting
Base Unit
GA500 V1000 GA500 V1000
