YASKAWA V1000 - Single-Phase 240 V Models; Three-Phase 240 V Models; Replacement GA500 Drive Selection

2 Replacement GA500 Drive Selection
YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide 5
2 Replacement GA500 Drive Selection
Table 1 through Table 3 provide a model to model cross reference. Select the GA500 model that corresponds to your
V1000 model.
Increasing the Carrier Frequency parameter C6-02 from the factory default setting may require derating of the drive
capacity. Refer to Carrier Frequency - C6-02 [Carrier Frequency Selection] on page 40 to understand the effect of
changing parameter C6-02 on your new replacement drive.
Note: Normal Duty overload tolerance.
• V1000 120% of rated normal duty current for 60 seconds.
• GA500 110% of rated normal duty current for 60 seconds.
Table 1 Single-Phase 240 V Models
Table 2 Three-Phase 240 V Models
V1000 Model
CIMR-VU
Rated Output
Heavy Duty (HD)
Amps
Rated Output
Normal Duty (ND)
Amps
GA500 Catalog
Code
GA50U
Rated Output
Heavy Duty (HD)
Amps
Rated Output
Normal Duty (ND)
Amps
BA0001 0.8 1.2
 B001 0.8 1.2
BA0002 1.6 1.9  B002 1.6 1.9
BA0004 3.0 3.3
 B004 3.0 3.5
BA0006 5.0 6.0  B006 5.0 6.0
BA0010 8.0 9.6
 B010 8.0 9.6
BA0012 11.0 12.0  B012 11.0 12.2
BA0018 17.5 -
 B018 17.6 -
V1000 Model
CIMR-VU
Rated Output
Heavy Duty (HD)
Amps
Rated Output
Normal Duty (ND)
Amps
GA500 Catalog
Code
GA50U
Rated Output
Heavy Duty (HD)
Amps
Rated Output
Normal Duty (ND)
Amps
2A0001 0.8 1.2  2001 0.8 1.2
2A0002 1.6 1.9  2002 1.6 1.9
2A0004 3.0 3.5  2004 3.0 3.5
2A0006 5.0 6.0  2006 5.0 6.0
2A0010 8.0 9.6  2010 8.0 9.6
2A0012 11.0 12.0  2012 11.0 12.2
2A0020 17.5 19.6  2021 17.6 21.0
2A0030 25.0 30.0  2030 25.0 30.0
2A0040 33.0 40.0  2042 33.0 42.0
2A0056 47.0 56.0  2056 47.0 56.0
2A0069 60.0 69.0  2070 60.0 70.0
- - - 2082 75.0 82.0
