9 Watt Loss Comparison
Use this section to understand the watt loss difference between the V1000 and GA500. This is useful to ensure proper
cooling for GA500 drives that replace V1000 drives inside of enclosures.
Understanding the “Difference” columns in Table 16 through Table 21.
• A positive number = GA500 has more watt loss compared to V1000.
• A negative number = GA500 has less watt loss compared to V1000.
 Normal Duty (Parameter C6-01=1, factory default)
Table 16 Single-Phase 240 V Models, Watt Loss Comparison
Table 17 Three-Phase 240 V Models, Watt Loss Comparison
Table 18 Three-Phase 480 V Models, Watt Loss Comparison
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
BA0001 Swing 2 kHz 5.0 8.5 13.5 B001 2.0 8.0 6.0 14.0 3.0 -2.5 0.5
BA0002 Swing 2 kHz 7.6 9.7 17.3 B002 2.0 14.0 11.0 25.0 6.4 1.3 7.7
BA0004 Swing 2 kHz 14.6 14.4 29.1 B004 2.0 14.0 17.0 31.0 -0.6 2.6 1.9
BA0006 Swing 2 kHz 30.1 19.4 49.5 B006 2.0 17.0 26.0 43.0 -13.1 6.6 -6.5
BA0010 Swing 2 kHz 51.7 29.8 81.4 B010 2.0 36.0 50.0 86.0 -15.7 20.2 4.6
BA0012 Swing 2 kHz 61.3 37.1 98.4 B012 2.0 48.0 60.0 108.0 -13.3 22.9 9.6
BA0018 Swing 2 kHz — — — B018 2.0 49.0 92.0 141.0 N/A N/A N/A
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
2A0001 Swing 2 kHz 5.0 8.0 13.0 2001 2.0 7.0 5.0 12.0 2.0 -3.0 -1.0
2A0002 Swing 2 kHz 7.6 9.5 17.1 2002 2.0 9.0 9.0 18.0 1.4 -0.5 0.9
2A0004 Swing 2 kHz 15.8 13.6 29.4 2004 2.0 11.0 16.0 27.0 -4.8 2.4 -2.4
2A0006 Swing 2 kHz 27.5 17.2 44.7 2006 2.0 14.0 25.0 39.0 -13.5 7.8 -5.7
2A0010 Swing 2 kHz 51.7 25.8 77.5 2010 2.0 25.0 51.0 76.0 -26.7 25.2 -1.5
2A0012 Swing 2 kHz 61.3 30.4 91.7 2012 2.0 30.0 61.0 91.0 -31.3 30.6 -0.7
2A0020 Swing 2 kHz 98.7 46.3 145.0 2021 2.0 52.0 111.0 163.0 -46.7 64.7 18.0
2A0030 Swing 2 kHz 246.4 88.9 335.3 2030 2.0 63.0 240.0 303.0 -183.4 151.1 -32.3
2A0040 Swing 2 kHz 266.7 112.8 379.6 2042 2.0 84.0 307.0 391.0 -182.7 194.2 11.4
2A0056 Swing 2 kHz 357.9 151.8 509.7 2056 2.0 109.0 367.0 476.0 -248.9 215.2 -33.7
2A0069 Swing 2 kHz 461.7 184.5 646.2 2070 2.0 142.0 534.0 676.0 -319.7 349.5 29.8
- - - - - 2082 2.0 160.0 531.0 691.0 N/A N/A N/A
V1000 GA500 Difference
Model
Carrier
kHz
Watt Loss
Catalog
Code
Watt Loss Watt Loss
CIMR-VU Interior External Total GA50U
Carrier
kHz
Interior External Total Interior External Total
4A0001 Swing 2 kHz 10.0 9.6 19.6 4001 2.0 8.0 7.0 15.0 -2.0 -2.6 -4.6
4A0002 Swing 2 kHz 18.5 13.9 32.4 4002 2.0 13.0 12.0 25.0 -5.5 -1.9 -7.4
4A0004 Swing 2 kHz 30.5 16.8 47.3 4004 2.0 14.0 24.0 38.0 -16.5 7.2 -9.3
