4 Branch Circuit Protection
YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide 9
4 Branch Circuit Protection
Use this section to understand if the existing V1000 branch circuit protection is suitable for the replacement GA500 drive.
V1000 Branch Circuit Protection
Table 7 V1000 Branch Circuit Protection
Drive Model
CIMR-VU
Fuse Type: Class T, Non-Time Delay
(Manufacturer: Ferraz)
Rating: 600 Vac, 200 kAIR
Fuse Type: Semiconductor Fuse, Fast Acting
(Manufacturer: Bussmann)
Rating: 500 Vac, 200 kAIR
Fuse Amp Fuse Amp
Single-Phase 240 V
BA0001 A6T6 6 FWH-25A14F 25
BA0002 A6T10 10 FWH-25A14F 25
BA0004 A6T20 20 FWH-60B 60
BA0006 A6T40 40 FWH-80B 80
BA0010 A6T40 40 FWH-100B 100
BA0012 A6T50 50 FWH-125B 125
BA0018 A6T80 80 FWH-175B 175
Three-Phase 240 V
2A0001 A6T3 3 FWH-25A14F 25
2A0002 A6T6 6 FWH-25A14F 25
2A0004 A6T15 15 FWH-25A14F 25
2A0006 A6T20 20 FWH-25A14F 25
2A0010 A6T25 25 FWH-70B 70
2A0012 A6T25 25 FWH-70B 70
2A0020 A6T40 40 FWH-90B 90
2A0030 – – FWH-100B 100
2A0040 – – FWH-200B 200
2A0056 – – FWH-200B 200
2A0069 – – FWH-200B 200
Three-Phase 480 V
4A0001 A6T3 3 FWH-40B 40
4A0002 A6T6 6 FWH-40B 40
4A0004 A6T15 15 FWH-50B 50
4A0005 A6T20 20 FWH-70B 70
4A0007 A6T25 25 FWH-70B 70
4A0009 A6T25 25 FWH-90B 90
4A0011 A6T30 30 FWH-90B 90
4A0018 – – FWH-80B 80
4A0023 – – FWH-100B 100
4A0031 – – FWH-125B 125
4A0038 – – FWH-200B 200
