YASKAWA V1000

3 Dimensions and Adapters
8 YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide
Table 5 Three-Phase, 240 V Models - Exterior Dimensions and Enclosure Kits
Table 6 Three-Phase, 480 V Models - Exterior Dimensions and Enclosure Kits
V1000
Frame
V1000
Model
GA500
Frame
GA500
Catalog
Code
GA50U_
GA500
UL Type 1
Enclosure Kit
V1000
UL Type 1
Enclosures
GA500
Protected Chassis
Enclosures
GA500
IP20/UL Type 1
Enclosures
CIMR-VU GA50U Catalog Code H x W x D in H x W x D in H x W x D in
1 2A0001 1.1 2001
ZBAA-GA50V1-1
5.89 x 2.68 x 2.99 5.04 x 2.68 x 2.99 5.83 x 2.68 x 2.99
1 2A0002 1.1 2002
2 2A0004 1.2 2004 5.89 x 2.68 x 4.25 5.04 x 2.68 x 4.25 5.83 x 2.68 x 4.25
4 2A0006 1.4 2006 5.89 x 2.68 x 5.04 5.04 x 2.68 x 5.04 5.83 x 2.68 x 5.04
7 2A0010 2.3 2010 ZBAA-GA50V2-3 5.89 x 4.25 x 5.08 5.04 x 4.25 x 5.08 7.01 x 4.25 x 5.08
8 2A0012 2.4 2012 ZBAA-GA50V2-1 5.89 x 4.25 x 5.41 5.04 x 4.25 x 5.41 7.01 x 4.25 x 5.41
11 2A0020 3.1 2021 ZBAA-GA50V3-2 6.02 x 5.51 x 5.63 5.04 x 5.51 x 5.63 7.01 x 5.51 x 5.63
14 2A0030 5 2030
ZBAA-GA50V5-1 10 x 5.51 x 5.51 10.24 x 5.51 x 5.51 11.73 x 5.51 x 5.51
14 2A0040 5 2042
16 2A0056 6 2056 ZBAA-GA50V6-1 11.42 x 7.09 x 6.42 11.81 x 7.09 x 5.63 13.39 x 7.09 x 5.63
17 2A0069 7 2070
ZBAA-GA50V7-1
14.09 x 8.66 x 7.36 13.78 x 8.66 x 7.36 15.87 x 8.66 x 7.36
- - 7 2082 - 13.78 x 8.66 x 7.36 15.87 x 8.66 x 7.36
V1000
Frame
V1000
Model
GA500
Frame
GA500
Catalog
Code
GA50U_
GA500
UL Type 1
Enclosure Kit
V1000
UL Type 1
Enclosures
GA500
Protected Chassis
Enclosures
GA500
IP20/UL Type 1
Enclosures
CIMR-VU GA50U Catalog Code H x W x D in H x W x D in H x W x D in
5 4A0001 2.1 4001 ZBAA-GA50V2-4 5.89 x 4.25 x 3.19 5.04 x 4.25 x 3.19 5.87 x 4.25 x 3.19
6 4A0002 2.2 4002 ZBAA-GA50V2-5 5.89 x 4.25 x 3.9 5.04 x 4.25 x 3.9 5.87 x 4.25 x 3.9
8 4A0004 2.4 4004
ZBAA-GA50V2-2
5.89 x 4.25 x 5.41 5.04 x 4.25 x 5.41 5.87 x 4.25 x 5.41
9 4A0005 2.5 4005
5.89 x 4.25 x 6.06 5.04 x 4.25 x 6.06 7.01 x 4.25 x 6.06
9 4A0007 2.5 4007
9 4A0009 2.5 4009
ZBAA-GA50V3-2
5.89 x 4.25 x 6.06 5.04 x 4.25 x 6.06 7.01 x 4.25 x 6.06
11 4A0011 3.1 4012 6.02 x 5.51 x 5.63 5.04 x 5.51 x 5.63 7.01 x 5.51 x 5.63
14 4A0018 5 4018
ZBAA-GA50V5-1 10 x 5.51 x 5.51 10.24 x 5.51 x 5.51 11.73 x 5.51 x 5.51
14 4A0023 5 4023
15 4A0031 6 4031
ZBAA-GA50V6-1
11.42 x 7.09 x 5.63 11.81 x 7.09 x 5.63 13.39 x 7.09 x 5.63
16 4A0038 6 4038 11.42 x 7.09 x 6.42 11.81 x 7.09 x 5.63 13.39 x 7.09 x 5.63
- - 8 4044
ZBAA-GA50V8-1
-
13.78 x 7.48 x 8.03 15.87 x 7.48 x 8.03
--84060 -
