7 Transfer of Parameter Settings
YASKAWA America, Inc. PL.GA500.01 YASKAWA AC Drive - V1000 to GA500 Transition Guide 39
0x0705 T1-05
Motor Base
Frequency
Sets the base frequency of the motor in Hertz
(Hz).
0.0~590.0 0.0~400.0 60.0 60.0
DEC Hz
0x0706 T1-06
Number of Motor
Poles
Sets the number of motor poles.
2~120 2~48 4 4
DEC
0x0707 T1-07 Motor Base Speed
Sets the base speed of the motor in revolutions
per minute (RPM).
0~35400 0~24000 1750 1750
DEC
RPM
0xBdB T1-12
Test Mode
Selection
Enables the Test Mode after performing
Stationary Auto-Tuning.
Enable this setting if it is possible to operate the
motor with a light load attached after Stationary
Auto-Tuning is complete.
Note:
This selection is possible when T1-10 [Motor
Rated Slip Frequency] = 0 Hz.
0: No
1: Yes
0~1 0~0 0 0
DEC
Reg.
No.
Param.
No.
Name Description
Setting Range Initial Setting
Base Unit
GA500 V1000 GA500 V1000
