- xv -
Do not touch circuit components until main input power has been turned
OFF. Status indicator LEDs and Digital Operator display will be extinguished
when the DC bus voltage is below 50 VDC. Wait 5 additional minutes.
Do not connect or disconnect wires and connectors while the main input
power is turned on.
(1)
47P5 drive, with a current rating of 21.0 A and nominal horsepower of 15, is only
available as a V74X drive.
The Drive leaves the factory with parameters initialized for 2-Wire control
(when using external Run/Stop signals). Before using the initialization
function of constant n001, know your control wiring configuration:
10 = Factory 2-Wire Control Initialization (Maintained RUN Contact)
11 = Factory 3-Wire Control Initialization (Momentary START/STOP
Contact)
Entering either Initialization code resets all parameters to factory settings,
and automatically returns parameter n001 setting to “ 1 ”. If the Drive is
connected for 3-Wire control and this parameter is set to “ 10 ” (2-Wire
Control Initialization), the motor may run in reverse direction WITHOUT A
RUN COMMAND APPLIED. Equipment damage or personal injury may
result.
Rated Current Nominal Model Number
Input Voltage Rating [A] Horsepower
CIMR-V7* MV
0.8 1/8 20P1 A001
1.6 1/4 20P2 A002
3.0 1/2 20P4 A003
5.0 3/4 & 1 20P7 A005
230V 8.0 2 21P5 A008
11.0 3 22P2 A011
17.5 5 23P7 A017
25.0 7.5 25P5 A025
33.0 10 27P5 A033
1.2 1/2 40P2 B001
1.8 3/4 40P4 B002
3.4 1 & 2 40P7 B003
460V 4.8 3 41P5 B005
5.5 3 42P2 –
8.6 5 43P7 B009
14.8 7.5 & 10 45P5 B015
21.0
(1)
15
(1)
47P5
(1)
–
Current Ratings & Horsepower Range
