150
n035 Settings
Setting Description
0 • Setting unit: 0.01 Hz (less than 100 Hz), 0.1 Hz (100 Hz and
more)
• Setting range
Min {Fmax (n011) × Frequency Reference Lower Limit (n034)
to Fmax (n011) × Frequency Reference Upper Limit (n033),
400 Hz}
1 • Setting in units of 0.1%: 100.0%/Fmax (n011)
• Setting range
Min. {Frequency Reference Lower Limit (n034) to Frequency
Reference Upper Limit (n033), (400 Hz ÷ Fmax. (n011)) 100%}
Max. Upper Limit Value: Fmax. (n011) × Set value (%) ≤ 400 Hz
2 to 39
• Setting in units of 1 min
-1
: min
-1
=120 × Frequency reference
(Hz) ÷ n035 (Set the number of motor poles in n035)
• Setting range
Min. {120 × (Fmax (n011) Frequency Reference Lower Limit
(n034) ÷ n035 to 120 × (Fmax (n011) × Frequency Reference
Upper Limit (n033)) ÷ n035, 400 Hz × 120 ÷ P, 9999 min
-1
• Max. Upper Limit Value: N × P ÷ 120 ≤ 400 Hz
40 to
3999
• Set the display value at 100% of frequency reference (set value
of Fmax (n011)) at 1st to 4th digits of n035.
In the 4th digit of n035, set the position of decimal point.
In the 1st to 3rd digits of n035, set a 3-digit figure excluding the
decimal point.
4th digit Position of decimal point
0
1 .
2 .
30.
Example: To display 20.0 at 100% of frequency reference, set
n035 to 1200.
• Setting range
Min. {(Lower 3-digits of n035) × Frequency Reference Lower
Limit (n034) to (Lower 3-digits of n035) × Frequency Reference
Upper Limit (n033), 400 Hz × (Lower 3-digits of n035) ÷ Fmax
(n011), 999}
Max. Upper Limit Value: (Set value ÷ (Lower 3 digits of n035)) ×
Fmax(011) ≤ 400 Hz
