180
9. Specifications
Standard Specifications (200 V Class)
Voltage Class 200 V single-/3-phase
Model
CIMR-
V7∗T
3-phase 20P1 20P2 20P4 20P7 21P5 22P2 23P7 25P5 27P5
Single-phase B0P1 B0P2 B0P4 B0P7 B1P5 B2P2 B3P7 - -
Max. Applicable Motor Output
kW
*1
0.1 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Inverter Capacity (kVA) 0.3 0.6 1.1 1.9 3.0 4.2 6.7 9.5 13
Rated Output Current
(A)
0.8 1.6 3 5 8 11 17.5 25 33
Max. Output Voltage (V) 3-phase, 200 to 230 V (proportional to input voltage)
Single-phase, 200 to 240 V (proportional to input voltage)
Max. Output Frequency
(Hz)
400 Hz (Programmable)
Rated Input Voltage and
Frequency
3-phase, 200 to 230 V, 50/60 Hz
Single-phase, 200 to 240 V, 50/60 Hz
Allowable Voltage
Fluctuation
−15 to +10%
Allowable Frequency
Fluctuation
±5%
Control Method Sine wave PWM (V/f control/vector control selectable)
Frequency Control
Range
0.1 to 400 Hz
Frequency Accuracy
(Temperature Change)
Digital reference: ±0.01% (−10 to 50°C)
Analog reference: ±0.5% (25 ±10°C)
Frequency Setting
Resolution
Digital reference:
0.01 Hz (less than 100 Hz)/0.1 Hz (100 Hz or more)
Analog reference: 1/1000 of max. output frequency
Output Frequency
Resolution
0.01 Hz
Overload Capacity 150% rated output current for one minute
Frequency Reference
Signal
0 to 10 VDC (20 kΩ), 4 to 20 mA (250 Ω), 0 to 20 mA (250 Ω) pulse train
input, frequency setting potentiometer (Selectable)
Output CharacteristicsPower SupplyControl Characteristics
