9. Specifications
193
Sequence Connection with PNP Transistor (+24 V Common)
VS-606V7
SW1 NPN
PNP
+24 V
SC
S1
S2
S3
S4
S5
S6
S7
External
power
supply
+24V
JOG
command
Multi-step speed
reference 1
Multi-step speed
reference 2
Fault reset
External
fault (NO)
Reverse
run/stop
Forward
run/stop
Multi-
function
input
