Operation Steps Operator
Display
Function
Indicators
Status
Indicators
1. Turn the potentiometer fully counter-
clockwise, and then turn the power ON.
0.00
2. F/R will lit.
Select FOR or REV RUN using the
keys.
Never select REV when reverse
run is prohibited.
(Forward)
or
(Reverse)
3. Press DSPL to make FREF lit. Then
press RUN.
0.00
4. Operate the motor by turning the poten-
tiometer clockwise. (A frequency refer-
ence corresponding to the
potentiometer position will be dis-
played.)
If the potentiometer is switched
rapidly, the motor also acceler-
ates or decelerates rapidly in
proportion to the potentiometer
movement. Pay attension to
load status and switch the poten-
tiometer at the speed that will
not adversely affect motor move-
ment.
0.00 to
60.00
Minimum
output fre-
quency is
1.50 Hz
FREF
RUN
ALARM
NOTE
F/R
RUN
ALARM
FREF
RUN
ALARM
NOTE
FREF
RUN
ALARM
Status indicators : ON : Flashing : OFF
To Next Page
