WIRING
(Ref. page)
• Only begin wiring after verifying that the power
supply is turned OFF.
Failure to observe this warning may result in an elec-
tric shock or a fire.
30
• Wiring should be performed only by qualified
personnel.
Failure to observe this warning may result in an elec-
tric shock or a fire.
30
• When wiring the emergency stop circuit, check
the wiring thoroughly before operation.
Failure to observe this warning may result in injury.
30
• Always ground the ground terminal accord-
ing to the local grounding code.
Failure to observe this warning may result in an elec-
tric shock or a fire.
36
• For 400 V class, make sure to ground the sup-
ply neutral.
Failure to observe this warning may result in an elec-
tric shock or a fire.
30
• If the power supply is turned ON during the
FWD (or REV) RUN command is given, the
motor will start automatically.
Turn the power supply ON after verifying that
the RUN signal is OFF.
Failure to observe this warning may result in injury.
39
• When the 3-wire sequence is set, do not make
the wiring for the control circuit unless the multi-
function input terminal parameter is set.
Failure to observe this warning may result in injury.
92
WARNING
