Yealink CTP20 User Manual

| Getting Started | 22
Related information
LED Indicators of the VCS Devices
Rear Panel of VC500 Codec
Port Name Description
1 USB
• Insert a USB flash drive.
USB flash drive can be used for storing screenshots, recorded
videos or captured packets. If you insert multiple USB flash
drives to the VCS endpoint simultaneously, only the last USB
flash drives you insert can be identified by the endpoint.
• Connect to an audio input device via a USB to line input adapter.
• Connect to an audio output device via a USB to line input
adapter.
• Insert a WF50 Wi-Fi USB Dongle for connecting to Wi-Fi or
providing wireless AP.
• Insert a BT42 Bluetooth USB Dongle for connecting to the
CPW90-BT Bluetooth wireless microphones.
• Insert a PSTN box CPN10 for connecting to the PSTN (Public
Switched Telephone Network).

Yealink CTP20 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Touchscreen technology	Capacitive
Number of simultaneous touchpoints	10
Product color	Black
Power consumption (typical)	7 W
Ethernet LAN (RJ-45) ports	1
OmniTapps Multitouch compatibility	No
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	196 mm
Width (without stand)	321.5 mm
Height (without stand)	118 mm
