Yealink CTP20 User Manual

| Getting Started | 37
Name Description
1 Built-in Microphone Supports 360-degree audio pickup at a radius of up to 3
meters.
2 Mute Key
• Indicates call status.
• Toggle mute feature.
Related information
Mute Indicator LED of CPE90 Wired Expansion Microphones
Hardware of CPW90-BT Bluetooth Wireless Microphone
CPW90-BT can expand the voice pick-up range, providing an optimal audio experience. You can connect
up to 2 CPW90-BTs to the VCS endpoint.
Name Description
1 Power Indicator LED Indicates the battery information.
2 Built-in Microphone Supports 360-degree audio pickup at a radius of up to 3 meters.
3 Mute Key
• Indicates call status.
• Toggle mute feature.
4 Charging Slot Put the CPW90-BT on the charging cradle to charge.
Related information
Battery Indicator LED
VCM38
VCM38 is a newly designed ceiling microphone with 8 built-in microphones, which can realize 360° voice
pickup range. VCM38 delivers excellent voice quality with high-quality echo cancellation and Yealink noise
proof technology. With Beamforming technology, VCM38 can automatically locate and optimize voice pick
up for the person speaking.
Front Panel of VCM38

Yealink CTP20 Specifications

General

Aspect ratio	16:9
Screen shape	Flat
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Touchscreen technology	Capacitive
Number of simultaneous touchpoints	10
Product color	Black
Power consumption (typical)	7 W
Ethernet LAN (RJ-45) ports	1
OmniTapps Multitouch compatibility	No
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (without stand)	196 mm
Width (without stand)	321.5 mm
Height (without stand)	118 mm
