7.11 Measurement Data
TIP
• Each phase/CH: indicates that measured data is available for each phase or each
channel.
• Inter-phase average: represents the average of each phase of voltage, current, power
factor, and phase angle.
• : represents the total of each phase of active power , reactive power, and apparent
power.
• f (frequency): shows the measured frequency of a signal selected for the frequency
source.
7.11.2 Integration Measurements
Normal measurement data
Instantaneous Values
Each Phase/CH
Inter-phase Average
Σ Each Load
Measurement Function
Voltage rms value
Current rms value
Active power
Reactive power
Apparent power
Power factor
Phase angle
Frequency
DC voltage (option)
Legend : measured data available : measured data not available
