7.11 Measurement Data
Electric energy and demand measurement data
Integrated Value/Demand Value
Σ Each Load
Measurement Function
Electric energy consumed
Regenerative energy
Lagging reactive energy
Leading reactive energy
Interval electric energy consumed
Interval regenerative energy
Interval lagging reactive energy
Interval leading reactive energy
Power consumption demand
Lagging reactive power demand
Power factor demand
Maximum demand
Date and time of occurrence of maximum demand
Legend : measured data available : measured data not available
Harmonic measurement data
Instantaneous Values
Each Phase Σ Each Load
Selected Order
*1
All Orders
*2
Measurement Function
Voltage rms value
Voltage content
Voltage phase angle
Current rms value
Current content
Current phase angle
Power value
Power content
Power phase angle
Voltage THD
Current THD
*1
Legend : measured data available : measured data not available
*1: Numerical data of any of the 1st to 50th.
*2: All orders means numerical data of all objective waveforms including the fundamental
wave and all harmonics.
