17-20
IM CW240E
Dimensions of Model 96035
96035
ø 170mm max.
0-300/3000A AC
0-500mV
±1.0% of rdg.
(45 to 66 Hz)
Within ±1.0°
3600A AC
(10 Hz to 1 kHz)
10 Hz to 20 Hz
1000V AC (primary side)
Approx.140mm×64mm×28mm
Approx.470g
Measurable conductor diameter
Measurement range
Output voltage
Amplitude
Accuracy
*1)
Phase
Maximum allowable current
*1)
Frequency range
Maximum applicable circuit voltage
External dimensions (W)×(H)×(D)
Weight
*1) Varies depending on the input level and frequency. For detailed specififications, refer to the
Users Manual that comes with the clamp-on power meter.
Item
17.2 Specifications of Current Clamps
