YOKOGAWA CW240

App.2-3
IM CW240E
Appendix
App
Header Characters
Category Header Characters Unit
DATE
Data output time
Normal Measurement Data (excluding 3P3W+1P3W)
Content
Data output date yyyy/mm/dd
U1_INST(V)
Voltage
Voltage 1 rms value
V
I1_INST(A)_1 to I1_INST(A)_4
Current
Current 1 rms value Loads 1 to 4
A
P_INST(W)_1 to P_INST(W)_4
Electric Power
Active power Loads 1 to 4
W
PF_INST_1 to PF_INST_4
Power Factor
Power factor Loads 1 to 4
PA_INST(deg)_1 to PA_INST(deg)_4
Phase Angle
Phase angle Loads 1 to 4
deg
F_INST(Hz)
Frequency
Each CH Value
Frequency
Hz
P1_INST(W)_1 to P1_INST(W)_2 Active power 1 Loads 1 and 2
W
DC1_INST(V)
DC Voltage
DC voltage CH1
V
Var
TIME Data output time hh:mm:ss
ETIME Elapsed time hhhhhh:mm:ss
U2_INST(V) Voltage 2 rms value
U3_INST(V) Voltage 3 rms value
Uave_INST(V)
Voltage rms value Average value
between CHs
I2_INST(A)_1 to I2_INST(A)_2 Current 2 rms value Loads 1 and 2
I3_INST(A)_1 to I3_INST(A)_2 Current 3 rms value Loads 1 and 2
Iave_INST(A)_1 to Iave_INST(A)_2
Current rms value Average value
between CHs Loads 1 and 2
I4_INST(A)_1 Current 4 rms value
P2_INST(W)_1 to P2_INST(W)_2 Active power 2 Loads 1 and 2
P3_INST(W)_1 to P3_INST(W)_2 Active power 3 Loads 1 and 2
Q2_INST(Var)_1 to Q2_INST(Var)_2 Reactive power 2 Loads 1 and 2
Q3_INST(Var)_1 to Q3_INST(Var)_2 Reactive power 3 Loads 1 and 2
S2_INST(VA)_1 to S2_INST(VA)_2 Apparent power 2 Loads 1 and 2
S3_INST(VA)_1 to S2_INST(VA)_2 Apparent power 3 Loads 1 and 2
PF2_INST_1 to PF2_INST_2 Power factor 2 Loads 1 and 2
PF3_INST_1 to PF3_INST_2 Power factor 3 Loads 1 and 2
PA2_INST(deg)_1 to PA2_INST(deg)_2 Phase angle 2 Loads 1 and 2
PA3_INST(deg)_1 to PA3_INST(deg)_2 Phase angle 3 Loads 1 and 2
DC2_INST(V) DC voltage CH2
Q_INST(Var)_1 to Q_INST(Var)_4 Reactive power Loads 1 to 4
VA
S_INST(VA)_1 to S_INST(VA)_4 Apparent power Loads 1 to 4
Var
Q1_INST(Var)_1 to Q1_INST(Var)_2 Reactive power 1 Loads 1 and 2
VA
S1_INST(VA)_1 to S1_INST(VA)_2 Apparent power 1 Loads 1 and 2
PF1_INST_1 to PF1_INST_2 Power factor 1 Loads 1 and 2
deg
PA1_INST(deg)_1 to PA1_INST(deg)_2 Phase angle 1 Loads 1 and 2
• For the average value, INST becomes AVE.
• For the maximum value, INST becomes MAX.
• For the minimum value, INST becomes MIN.
Appendix 2 File/Print Item Descriptions
