Category Header Characters Unit
Wh+_INTEG(Wh)_1 to Wh+_INTEG(Wh)_4
Electric
Energy
Normal Measurement Data (excluding 3P3W+1P3W)
Content
Varh–_INTEG(Varh)_1 to Varh–_INTEG(Varh)_4
Demand
Reactive electric energy (lag)
Loads 1 to 4
Reactive electric energy (lead)
Loads 1 to 4
Wh
Wh
Varh
Wh+_INTVL(Wh)_1 to Wh+_INTVL(Wh)_4
Active electric energy within
interval time (consumed) Loads 1 to 4
Wh–_INTEG(Wh)_1 to Wh–_INTEG(Wh)_4
Active electric energy (consumed)
Loads 1 to 4
Varh+_INTEG(Varh)_1 to Varh+_INTEG(Varh)_4
Active electric energy (regenerative)
Loads 1 to 4
Wh–_INTVL(Wh)_1 to Wh–_INTVL(Wh)_4
Active electric energy within
interval time (regenerative) Loads 1 to 4
Varh
Varh+_INTVL(Varh)_1 to Varh+_INTVL(Varh)_4
Reactive electric energy within
interval time (lag) Loads 1 to 4
W
P_DEM(W)_1 to P_DEM(W)_4
Average active power within
interval time (consumed) Loads 1 to 4
Var
Q_DEM(Var)_1 to Q_DEM(Var)_4
Average reactive power within
interval time (lag) Loads 1 to 4
PF_DEM_1 to PF_DEM_4
Average power factor within
interval time Loads 1 to 4
W
P_DEM_MAX(W)_1 to P_DEM_MAX(W)_4
Maximum demand value Active power
Loads 1 to 4
P_DEM_MAX_DATE_1 to P_DEM_MAX_DATE_4
Maximum demand date
yyyy/mm/dd Loads 1 to 4
P_DEM_MAX_TIME_1 to P_DEM_MAX_TIME_4
Maximum demand time
hh:mm:ss Loads 1 to 4
Varh–_INTVL(Varh)_1 to Varh–_INTVL(Varh)_4
Reactive electric energy within
interval time (lead) Loads 1 to 4
