Appendix 2 File/Print Item Descriptions
Category Header Characters
Unit
U1(n)_INST(V)
Harmonic
Level
Harmonic
Content
Harmonic
Phase Angle
Harmonic Measurement Data (excluding 3P3W+1P3W)
Content
nth order harmonic voltage 1 rms value
V
A
W
deg
%
U2(n)_INST(V) nth order harmonic voltage 2 rms value
U3(n)_INST(V) nth order harmonic voltage 3 rms value
I2(n)_INST(A)_1 to I2(n)_INST(A)_2
nth order harmonic current 2 rms value
Loads 1 and 2
I3(n)_INST(A)_1 to I3(n)_INST(A)_2
nth order harmonic current 3 rms value
Loads 1 and 2
I4(n)_INST(A)_1
nth order harmonic current 4 rms value
U1cont(n)_INST(%)
nth order harmonic voltage 1 content
U2cont(n)_INST(%)
nth order harmonic voltage 2 content
U3cont(n)_INST(%)
nth order harmonic voltage 3 content
I1cont(n)_INST(%)_1 to I1cont(n)_INST(%)_4
nth order harmonic current 1 content
Loads 1 to 4
I2cont(n)_INST(%)_1 to I2cont(n)_INST(%)_2
nth order harmonic current 2 content
Loads 1 and 2
I3cont(n)_INST(%)_1 to I3cont(n)_INST(%)_2
nth order harmonic current 3 content
Loads 1 and 2
I4cont(n)_INST(%)_1
nth order harmonic current 4 content
U1pa(n)_INST(deg)
nth order harmonic voltage 1 phase angle
U2pa(n)_INST(deg)
nth order harmonic voltage 2 phase angle
U3pa(n)_INST(deg)
nth order harmonic voltage 3 phase angle
I1pa(n)_INST(deg)_1 to I1pa(n)_INST(deg)_4
nth order harmonic current 1 phase
angle Loads 1 to 4
I2pa(n)_INST(deg)_1 to I2pa(n)_INST(deg)_2
nth order harmonic current 2 phase
angle Loads 1 and 2
I3pa(n)_INST(deg)_1 to I3pa(n)_INST(deg)_2
nth order harmonic current 3 phase
angle Loads 1 and 2
I4pa(n)_INST(deg)_1
nth order harmonic current 4 phase angle
Ppa(n)_INST(deg)_1 to Ppa(n)_INST(deg)_4
nth order harmonic electric power phase
angle Loads 1 to 4
Pcont(n)_INST(%)_1 to Pcont(n)_INST(%)_4
nth order harmonic electric power
content Loads 1 to 4
P(n)_INST(W)_1 to P(n)_INST(W)_4
nth order harmonic electric power value
Loads 1 to 4
I1(n)_INST(A)_1 to I1(n)_INST(A)_4
nth order harmonic current 1 rms value
Loads 1 to 4
• Any harmonic order of 01 to 50 is entered for n.
• For the average value, INST becomes AVE.
• For the maximum value, INST becomes MAX.
• For the minimum value, INST becomes MIN.
