App.2-6
IM CW240E
TOTAL_U1_INST(V)
Total Value
THD-F
(Selection)
THD-R
(Selection)
• Any harmonic order of 01 to 50 is entered for n.
• For the average value, INST becomes AVE.
• For the maximum value, INST becomes MAX.
• For the minimum value, INST becomes MIN.
Harmonic Measurement Data (excluding 3P3W+1P3W)
Voltage 1 total value (1st to 50th order)
V
A
W
%
%
TOTAL_U2_INST(V) Voltage 2 total value (1st to 50th order)
TOTAL_U3_INST(V) Voltage 3 total value (1st to 50th order)
TOTAL_I2_INST(A)_1 to TOTAL_I2_INST(A)_2
Current 2 total value (1st to 50th order)
Loads 1 and 2
TOTAL_I3_INST(A)_1 to TOTAL_I3_INST(A)_2
Current 3 total value (1st to 50th order)
Loads 1 and 2
TOTAL_I4_INST(A)_1 Current 4 total value (1st to 50th order)
THDF_U1_INST(%) Voltage 1 total harmonic distortion factor
THDF_U2_INST(%) Voltage 2 total harmonic distortion factor
THDF_U3_INST(%) Voltage 3 total harmonic distortion factor
THDF_I1_INST(%)_1
to
THDF_I1_INST(%)_4
Current 1 total harmonic distortion factor
Loads 1 to 4
THDF_I2_INST(%)_1
to
THDF_I2_INST(%)_2
Current 2 total harmonic distortion factor
Loads 1 and 2
THDF_I3_INST(%)_1
to
THDF_I3_INST(%)_2
Current 3 total harmonic distortion factor
Loads 1 and 2
THDF_I4_INST(%)_1 Current 4 total harmonic distortion factor
THDR_U1_INST(%) Voltage 1 total harmonic distortion factor
THDR_U2_INST(%) Voltage 2 total harmonic distortion factor
THDR_U3_INST(%) Voltage 3 total harmonic distortion factor
THDR_I1_INST(%)_1
to
THDR_I1_INST(%)_4
Current 1 total harmonic distortion factor
Loads 1 to 4
THDR_I2_INST(%)_1
to
THDR_I2_INST(%)_2
Current 2 total harmonic distortion factor
Loads 1 and 2
THDR_I3_INST(%)_1
to
THDR_I3_INST(%)_2
Current 3 total harmonic distortion factor
Loads 1 and 2
THDR_I4_INST(%)_1 Current 4 total harmonic distortion factor
TOTAL_P_INST(W)_1 to TOTAL_P_INST(W)_4
Electric power total value
(1st to 50th order) Loads 1 to 4
TOTAL_I1_INST(A)_1 to TOTAL_I1_INST(A)_4
Current 1 total value (1st to 50th order)
Loads 1 to 4
Category Header Characters
UnitContent
Appendix 2 File/Print Item Descriptions
To Next Page
